Multi-weighing units: Kg, lb, N are selectable, generally kg is the default unit.
Multi-function operation: Tare;Zero;Auto zero tracking;Total;Hold; Overload warning and record, operate through remote controller ,etc functions.
User-friendly design: Cast aluminium housing for maximum protection; Large red 5 digit LED display (digit height 30mm); Battery Operated with low battery indication; Automatic turn off , power-saving function.
Display | 30mm (1.2’’) 5digits LED |
Zero Range | 4% F.S. |
Tare Range | 100% F.S. |
Stable Time | ≤10seconds |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Life | ≥50 hours |
Battery Type | Fully sealed Lead-Acid battery, 6V/4.5Ah |
Adapter | DC9V / 1000 mA |
Operating Humidity | ≤85% RH under 20℃ |
Remote Controller Distance | Min. 15m |
Battery of Remote Controller | AAA battery, 1.5V×2 |
MODEL | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | H(mm) | G.W.(kg) |
DWS-CS-2 | 95 | 260 | 33 | 195 | 135 | 430 | 10.5 |
DWS-CS-3 | 95 | 260 | 40 | 195 | 135 | 455 | 11.5 |
DWS-CS-5 | 120 | 325 | 50 | 240 | 165 | 535 | 17.5 |
DWS-CS-10 | 124 | 325 | 60 | 240 | 165 | 660 | 27.5 |
DWS-CS-15 | 225 | 345 | 70 | 240 | 165 | 855 | 49 |
DWS-CS-20 | 225 | 345 | 85 | 240 | 165 | 920 | 56 |
3000|TON | DWS-CS-3 |
---|---|
5000|TON | DWS-CS-5 |
